Polarization
Insensitive Isolator
- Compact S+C Wideband
| ISBE
Series* |
Premium
|
Grade
A |
| Operating
Wavelength Range (nm) |
1450 ~ 1580 |
| Cross Band Isolation |
> 45 dB |
> 40 dB |
| Insertion Loss |
< 0.5 dB |
< 0.7 dB |
| Polarization Dependent Loss
|
< 0.1 dB |
< 0.15 dB |
| Polarization Mode Dispersion
|
< 0.05 ps |
< 0.05 ps |
| Optical Return Loss |
> 60 dB |
> 55 dB |
| Temperature Sensitivity
|
<
0.005 dB/°C |
| Max. Optical Power |
300 mW |
| Operating Temperature |
0 ~ +70°C |
| Storage Temperature |
-40 ~ +85°C
|
| Fiber Type |
Corning SMF-28
|
| Max. Tensile Load |
5 N |
| Package Design |
Gold-Plated Stainless
Steel Tube |
| Dimension |
f = 4.30 mm, L = 27 mm |
Target parameters are referenced without connectors.
* Patent pending
Reliability
Performance
Mechanical Test: Telcordia (GR-1209-CORE,
GR-1221-CORE, and GR-2882-CORE) compliant.
Endurance Test: Telcordia (GR-1209-CORE, GR-1221-CORE,
and GR-2882-CORE) compliant.
Details provided upon request. |
Compact Size
